Interlocking safety switches SND4121(SINGLE CONDUIT ENTRY)
|
Features： |
Specifications: Operating Frequency:Mechanical: 120ops/min Electrical: 30 ops/min Insulation Resistance:>100MW@500V DC Contact Resistance:<25mW(initial value) Rated Voltage:300V AC (EN60947-5-1) Rated Thermal Current:5A Electrical Rating:AC15 B300 DC13 R300 Dielectric Strength:1000VAC for 1 min between current carrying parts 2500VAC for 1 min between non-current carrying parts Operating Temperature:-25~+85oC without formation of ice Humidity:< 95%RH Degree of Protection:IP67 |
|
