Features: *Robust design for marine or medical applications
*Double break action contact
*High shock and vibration resistant
*Positve tactile feedback
*Solder and screw terminals
*Meet Mil-PRF-8805 standard
*IP68 rated |
Installation dimensions:
![](/en/d/file/p/2023-05-10/PP12-2-112-G 尺寸图.jpg) |
Specifications: Housing Material: Thermoplastic/Anodized aluminum alloy
Button Material: Thermoplastic
Contact Resistance: <50mW (Initial)
Dielectric Strength: 1000VAC for 1 minute between current carrying parts
2000VAC for 1 minute between non-current carrying parts
Operating Force: ~4 lbs (18N) or 2.5 lbs (11N)
OperatingTemperature: -55~+85oC (-67 ~185oF)
Mechanical Life: 1 million (operatings)
Electrical Life Resistive load 5A 25,000 (operations)
(@28VDC or 115VAC): Inductive load 3A 25,000 (operations)
Degree of Protection: IP68
|
TRADEMARK INFORMATION:
All trademarks, trade names, or logos mentioned or used are the property of their respective owners.
-
![PP12选型.jpg](/en/d/file/p/2023-05-10/PP12选型.jpg)
