General-purpose Mirco Switches Z-20GW
|
Features： |
Specifications: Operating speed: 0.01mm-1m/sec operating frequency: Mechanical:240 ops/min Electrical:20ops/min Insulation Resistance:>100MΩ@500V Rated Voltage/Current: 20A,125/250/480VAC,1.5HP/125VAC or 2HP/250VAC Service Life: Mechanically 1×107 (operations) Electrically 5×105 (operations) Operating Temperature: about -25~+80 (-4~+176) Humidity: <95%RH Degree of protection IP00/IP63 Delectric Strength: 1000VAC for 1 min between current carrying parts 2500VAC for 1 min between non-current carrying parts |
|
