FS-6 Foot Switches

Features: * Robust aluminum alloy die cast body * Choice of different type of contact blocks * Water-proof to IP65(IP67 available on special request) * Galvanically separated contacts * Screw terminals with self-lifting clamps for easy wirting * Positive Opening of NC contacts * Safety reset option available * UL/CUL approval(E216958) * Threaded Hole available in:PG 13.5,m20x1.5 and 1/2NPT

Installation dimensions:

Specifications: Operating Frequency: 60 ops/min Insulation Resistance: >100mΩ@500VDC Contact Resistance: <25mΩ Rated Current/Voltage 10A/600V AC A600/AC15 Q300/DC13 Inrush Current Complies with IEC947-5-1:AC15/DC 13 Dielectric Strength: 1000VAC for 1 min between current carrying parts 2500VAC for 1 min between non-current carrying parts Service Life: Mechanically 1.0×106(operations) Electrically 5×105 (operations) Operating Temperature:-30~+80℃(-22~176°F) Degree of Protection: IP65 (IP68 available on request)

TRADEMARK INFORMATION:
All trademarks, trade names, or logos mentioned or used are the property of their respective owners.

For example：FS-61	-G	-SP	-A	-S	-K	-A
Single pedal	Guarding options	Contact Block Type	Special Features	Switch Configuration	option	Conduit Type
	blank:No Guarded	SP: snap action	blank	blank:SPDT	blank	A: 1/2NPT
	G: Fully Guarded	SL:slow action break before make	A: Anti-tripped	T:DPDT	K:Gold plated contactcs	B:PG13.5
		SL1:slow action make before break		S: 2 stages		C:M20x1.5

TRADEMARK INFORMATION:
All trademarks, trade names, or logos mentioned or used are the property of their respective owners.

TYPE:FS-61 View Details	TYPE:FS-61G View Details	TYPE:FS-61G-SP-A-A View Details
TYPE:FS-62-SP View Details	TYPE:FS-62G-SP-A View Details	TYPE:FS-62G-SP View Details
TYPE:FS-62G-SP-A-C(RAL7016) View Details
